The MultiVoice Gateway
is based on the MAX/TNT™ family of access concentrators, which has an installed
base of more than 80,000 systems and 20 million ports worldwide. The MAX
TNT supports from 2 T1/E1 to 1 T3 (48 to 672 channels). It is a scalable,
standards-based gateway that provides an interface between the PSTN and
an IP-based network, enabling voice calls to hop on and off the packet
network. The gateway incorporates DSP modules to
provide the high-quality signal compression and low latencies required
for voice and fax calling. In addition, the Lucent True Access™ Operating
System (TAOS) used in all MAX/TNT products provides reliable access routing
and the worldwide circuit signaling support required for rapid deployment
of global voice and data networks. |
The MAX TNT gateway:
-
Supports a variety of trunking and signaling options:
T1/E1/T3, PRI, CAS, R2, Feature Group D.
-
Provides flexible space and power requirements including
NEBS Level 3 and ETSI requirements.
-
Is approved for use in more than40 countries.
-
Can be operated as a dark site with remote monitoring
and low maintenance requirements.
-
Has an extensive list of more than 60 features enabling
voice and fax services. number translations, and programmable call flows.
Specifically, the MVAM:
-
Manages the H.323 zone for a set of MultiVoice gateways
and PC endpoints, up to 30,000 ports on one gatekeeper.
|
Specifically, the
MVAM:
-
Manages the H.323 zone for a set of MultiVoice gateways
and PC endpoints, up to 30,000 ports on one gatekeeper.
-
Processes and records 50 calls per second.
-
Supports a secondary MultiVoice Access Manager for
redundancy.
-
Enables communication among multiple MultiVoice Access
Managers to connect calls between zones.
-
Can be deployed on standard Windows NT1 or Sun SOLARIS2
platforms for maximum scalability, flexibility, and cost-effectiveness.
-
Facilitates programmable call flows, based on individual
call parameters such as DNIS or trunk group.
-
Provides routing among gateways.
-
Performs digit stripping and number translations for
dialed long-distance and international calling.
|
